Twin screw pump
    Publish time 2018-06-26 15:35
Twin screw pump


1、W series twin-screw pump




Features:
   Horizontal installation, flange connection.
   Strong self-priming ability
   low noise, no pulsation, no emulsifying shearing effect on the medium
   Gas-liquid mixed transportation


Performance range:
  Flow Q: ~2000 m3/h
  Temperature t: -20℃~350℃
   Differential pressure △P: ~6.0MPa


Range of application:
   It is suitable for transporting lubricating and non-lubricating liquids. It is widely used in oil field, petrochemical, shipbuilding, thermal power plant, food, paint, and other industries.






W series twin-screw pump


Features:

   Horizontal installation, flange connection.

   Strong self-priming ability

   low noise, no pulsation, no emulsifying shearing effect on the medium

   Gas-liquid mixed transportation


Performance range:

  Flow Q: ~2000 m3/h

  Temperature t: -20℃~350℃

   Differential pressure △P: ~6.0MPa


Range of application:

   It is suitable for transporting lubricating and non-lubricating liquids. It is widely used in oil field, petrochemical, shipbuilding, thermal power plant, food, paint, and other industries.



2、2HC/R/M/E/H series twin-screw pump



Features:
   Horizontal installation, flange connection.
   Strong self-priming ability
   low noise, no pulsation, no emulsifying shearing effect on the medium
   Gas-liquid mixed transportation


Performance range:
  Flow Q: -2700 m3/h
  Temperature t: -20℃-300℃
   Differential pressure △P: -2.5MPa


Range of application:
   It is suitable for transporting lubricating and non-lubricating liquids. It is widely used in oil field, petrochemical, shipbuilding, thermal power plant, food, paint, and other industries.




3、V series vertical twin-screw pump



Features:
   Horizontal installation, flange connection.
   Strong self-priming ability
   low noise, no pulsation, no emulsifying shearing effect on the medium

Performance range:
  Flow Q: ~1200 m3/h
  Temperature t: -20℃~300℃
   Differential pressure △P: ~2.5MPa


Range of application:
   It is suitable for transporting lubricating and non-lubricating liquids. It is widely used in oil field, petrochemical, shipbuilding, thermal power plant, food, paint, and other industries.



4、HPW series twin-screw pump



Features:
   Horizontal installation, flange connection.
  Ultra-short shaft, double-suction structure, and the pump body is a welded type.


Performance range:
  Flow Q: ~1000 m3/h
  Temperature t(max): 100℃
   Differential pressure △P: ~10.0MPa


Range of application:
   It is mainly used in petroleum, chemical industry, wharf, pumping station, etc. As a long-distance high-pressure conveying pump, it can convey fluids of various viscosities.



5、2G series twin-screw pump



Features:
   Horizontal installation, flange connection.
   Strong self-priming ability
   low noise, no pulsation, no emulsifying shearing effect on the medium
   Gas-liquid mixed transportation


Performance range:
  Flow Q: -2700 m3/h
  Temperature t: -20℃-300℃
   Differential pressure △P: -2.5MPa


Range of application:
   It is suitable for transporting lubricating and non-lubricating liquids. It is widely used in oil field, petrochemical, shipbuilding, thermal power plant, food, paint, and other industries.



6、HW series twin screw pump





Features:

   Horizontal installation, flange connection.

  The special structure design makes the pump have strong dry running ability.

   When the inlet gas content of the pump fluctuates in the range of 0-100%, the mixture pump can work stably.


Performance range:

  Flow Q: ~2000 m3/h

   suction pressure: ~2.0Mpa

   discharge pressure: ~5.0Mpa

   Sand content: ≤ 2%

  The gas content is 98%, and the dry running time with 100% gas: 30-40 minutes.


Range of application:

   It is used for the transportation of multiphase flow, applied to onshore oil field, offshore oil field, and also can be applied to marginal oil field.
